Product introduction
OY-TO-1200 fixed oxygen probe is mainly used in measurement and control of temperature and oxygen, carbon or aluminum parameters in converter, ladle after furnace, argon blowing station, refining furnace and tundish and other processes, which can accurately and quickly determine the temperature and reactive oxygen content in molten steel, playing an important role in the smelting process and product quality control. The OY-TO-1200 constant oxygen probe has the characteristics of high measurement rate, good repeatability, high accuracy and fast response time, which can accurately guide the steelmaking production process and provide effective data support for the quality and efficiency improvement of steel mills.
Technical parameter
Medium and high oxygen probe | Low oxygen (fixed aluminum) probe | |
Product code | OY-DQ | OY-TO-AI |
Measuring range | 0.5-14ppm | 1-20ppm |
Recurrence rate | ±0.15ppm | ±3mv |
Measured rate | 96% | 96% |
Test time | 30-60s | 4-8S |
Temperature measurement | S/R/B models, temperature deviation ±3℃ | |
